The NEW FB-14 & FB-17
Key Basic Features
Introducing the new FB-14 and FB-17 from Nilpeter – the Future of Flexographic Printing – a continuation of the successful FB-350 and 430.
The new FB-14 and FB-17 continue the success of Nilpeter’s popular FB-Line. The FB-Line closely mirrors Nilpeter’s flexo flagship, the FA-Line, sharing the same touch, feel, and value-adding units. The press is designed with a new print head allowing for quick setup, rapid changeovers, and enhanced automation. Built on Nilpeter’s PowerLink platform, the modern FB-Line delivers high automation and performance. The future of flexo is here.
The upgraded and revamped version of Nilpeter’s FB-Line embodies The Future of Flexo, packed with automation and a number of features that address your business’s daily challenges and optimize operations. The new FB-Line boasts a range of specifications, including UV, Pre-register, Automatic Register, Ink Chamber System, and Single-die Unit.
The Opportunities
The new FB-Line, available in both 14″ and 17″, offers a range of possibilities for the modern printer.
Built on Nilpeter’s PowerLink platform and drawing inspiration from Nilpeter’s FA-Line, this press represents a leap forward in automation and digitalization, meeting the needs of future print operators.
The FB-14 and FB-17 Specifications
| General | Infeed |
| Press speed: 6-175 m/min | Web tension close loop – standard 20N-250N |
| Web width, max: 370 mm | Outfeed |
| Printing width, max: 355 mm | Web tension fixed speed offset – standard 300N |
| Web width Paper, min: 185 mm | Drying options |
| Web width Film/Foil min: 280 mm | Curing Standard UV |
| Repeat increments – Gears: 3.175 mm | Curing Optional LED |
| Die Cutting Rotary Width max: 355 mm | Hot Air Standard |
| Die Cutting Rotary Length: 203.2–609.6mm | Substrates |
| Unwind/Rewind Capacity | A wide variety of substrates from 15-300 μm |
| Pneumatic spindle dia.:76,2 mm | |
| Max.un/rewind dia./weight:1000 mm–300kg | |
| Standard Tension: 20N-250N | |
| Standard Tension: 20N-250N |
